HCPL-0931-000E General Description
Designed to meet the demands of various electronic systems, the HCPL-0931-000E optocoupler is compatible with both TTL and CMOS logic levels, allowing for seamless integration into a wide range of designs. Its 8-pin DIP package offers easy installation and space-saving benefits, making it a practical choice for industrial controls, power supplies, communication systems, and motor controls. Whether you’re looking to ensure signal integrity or protect components from electrical noise, this optocoupler provides the performance and reliability needed to meet your requirements
Features
- 15kV/µs Minimum common mode rejection
- 2500VRMS Isolation
- +3.3V and +5V TTL/CMOS compatible
- 15ns Maximum propagation delay
Application
- Computers & Computer Peripherals
- Industrial
Specifications
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Product Category | Digital Isolators | RoHS | True |
| Series | HCPL-0931 | Mounting Style | SMD/SMT |
| Package / Case | SOIC-8 | Number of Channels | 2 Channel |
| Polarity | Bidirectional | Data Rate | 100 Mb/s |
| Isolation Voltage | 2500 Vrms | Isolation Type | Magnetic Coupling |
| Supply Voltage – Max | 5.5 V | Supply Voltage – Min | 3 V |
| Operating Supply Current | 1.5 mA | Propagation Delay Time | 15 ns |
| Minimum Operating Temperature | – 40 C | Maximum Operating Temperature | + 100 C |
| Product | Digital Isolators | Product Type | Digital Isolators |
| Factory Pack Quantity | 100 | Subcategory | Interface ICs |
| Type | High-Speed |
Part points
- The HCPL-0931-000E is an optocoupler chip with a phototransistor output that provides electrical isolation between input and output signals. It is commonly used in industrial applications to prevent noise interference and voltage spikes from affecting sensitive components. The chip has a high isolation voltage and fast response time, making it ideal for electronic devices that require reliable signal transmission.
Equivalent
The equivalent products of HCPL-0931-000E chip are Avago ACPL-061L-000E and Broadcom ACPL-P346-560E optocouplers, as they have similar specifications and functionality for optical isolation and signal transmission in various applications.Features
HCPL-0931-000E is an optocoupler that features a high-speed operation, a high common-mode transient immunity, low input current requirements, and a wide operating temperature range of -40°C to 100°C. It is designed for use in communication systems, power supply control, and other high-speed signal isolation applications.Pinout
The HCPL-0931-000E is a single-channel optocoupler with 4 pins. Pin 1 is VCC, pin 2 is GND, pin 3 is the input, and pin 4 is the output. It is used for isolating and transferring high-speed digital signals between two circuits while providing electrical isolation.Manufacturer
The manufacturer of HCPL-0931-000E is Broadcom Inc. It is a global technology company that designs, develops, and supplies a broad range of semiconductor and infrastructure software solutions. Broadcom is known for its expertise in providing semiconductor and optical communication products for various industries, including networking, storage, and industrial markets.Application Field
HCPL-0931-000E is commonly used in industrial automation, power supply control, motor drives, and isolated interfaces for data communication. It is also used in medical equipment, test and measurement instruments, and renewable energy systems for high-speed and high-precision isolation applications.Package
The HCPL-0931-000E chip is a small outline, surface mount package with a form factor of SOIC-8. It measures 0.122″ x 0.189″ (3.10mm x 4.80mm) in size.
