• Fully integrated 3-axis magnetic sensor and electronic circuits requiring fewer external components

• Superior dynamic range and accuracy:±8G FSR、18bits operation、0.4mG total RMS noise、Enables heading accuracy of 0.5º

• Max output data rate of 1000Hz

• Industrial standard low profile package 3.0 x 3.0 x 1.0mm

• Degaussing with built-in SET/RESET function

• Eliminates thermal variation induced offset error (Null field output)

• Clears the residual magnetization resulting from strong external fields

• On-chip sensitivity compensation

• On-chip temperature sensor

• Data_Ready Interrupt

• Low power consumption

• 1μA 1µA power down current

• I²C Slave, FAST(≤400KHz) mode

• 3.0V single low power supply

• SPI interface available

• RoHS compliant
